Product: Tire Pressure Monitoring in GPS Tracking

fleet management | Tires Management| vehicles controlling | tire pressure monitoring in realtime

Model No.: Tire Pressure Monitoring in GPS Tracking

TPMS tracking is a different tire pressure monitoring system integrated into gps tracking solution, which offers new tires management for fleet managers and company bosses and end users. We focus on the technology about the tires with plenty of data displaying on APP and website.

Tire Pressure Monitoring Online

AT09, as TPMS receiver, integrates the GPS, GPRS/3G, RF433 technology into itself collecting intensive data from vehicles. AT09 is the base of tires management tracking software which allows users controls the human safety, security and enhance the productivity of tires use and prolong the tires life to lower down the maintenance cost on tires.

How does TPMS Monitoring Online Function in GPS tracking solution?

GPS devices continue receiving data including tires pressure, tire temperature, internal battery power from vehicles tires via TPMS part during driving. If vehicle is in parking status, no any trembles, GPS device and tire pressure sensors would get into sleep mode for saving power.

tire pressure monitoring in gps tracking solution


● Anti tires theft Realtime
● Monitoring tires pressure, tires temperature, sensor volt online
● alarms for tires pressure, tires temperature, sensor volt to server, APP
● alarm tire pressure value adjustable
● Replaceable battery for valve-cap sensor: CR1632
● valve-cap external sensors
● Anti theft sensors mounting design
● Intelligent power consumption on 3-Axis digital Accelerometer

tire Pressure Sensors supported by our GPS tracking device and TPMS display

caps tire pressure sensor
caps tire pressure sensor: TS06
caps tire pressure sensor for OTR, earth moving machines
TPMS sensor for large bore: TS06-LB
internal tire sensor
internal tire sensor: TS08
air flow through tire sensor
air flow through tire sensor: TS09
banded tire sensor
banded tire sensor: TS10

Click here for more details of TPMS sensors...

TPMS in GPS tracking in tracking software

TPMS in gps tracking in tracking software


 • Radial acceleration sensor, temperature sensor, supply voltage sensor
 • Embedded 8051 compatible 8-bit microcontroller
 • 6KB on-chip FLASH memory
 • 256Byte RAM
 • 315 and 434MHz FSK/ASK RF-transmitter
 • 125KHz ASK high-sensitivity LF-receiver
 •  Advanced power control/wake-up system to minimize battery consumption
 • Ultra low standby current

TPMS table in gps tracking in tracking software
history records of tire pressure monitoring in gps tracking in tracking software single tire history records of tire pressure monitoring in gps tracking in tracking software
You may check this video below for understanding this tps in gps tracking solution. Or you can check the video on Youtube.

Technical Properties

Monitor Specs:
Pressure Range
Temperature Setting Range
Operation Temperature
Storage Temperature
Power Supply
Battery Capacity
TPMS module
TPMS Receiver

Sensor Specs
Operation Temperature
Temperature Setting Range
Pressure Range
0-8 bar( 0-116psi)
Pressure Accuracy
Temperature Accuracy
Transmission Power
<10 dBm
Transmission Frequency
Battery Life
≥3 years

What Benefits From tire Pressure Monitoring Function In GPS Tracking

Anti tires theft
tire pressure sensors keep sending signal to TPMS receiver through RF433.92MHz at 4 minutes or so interval. If TPMS receiver or gps tracking device doesn't receive signal from one of sensors, and also gps tracking device detects continuous trembles, software platform would consider the tires theft happens.

Reduce tires maintenance cost, Extend the life of the tire
Overinflated or under-inflated would cause problems to tires. The outside of tire would be worn more than inside if under inflated; The center of tire's thread would be worn much if over inflated. TPMS function would alerts you if tires in over inflated or under inflated status. So users can adjust the tire pressure in properly inflated status. Proper inflation would make tires wear more evenly. It prolongs the tires life and reduce the tires maintenance cost. If you need to replace tires every 2 months, it's possible that you need to buy new tires every 3 months or longer.

Improve fuel economy and reduce CO2 emission
proper tire inflation would optimize tire performance and fuel economy. Under inflation increases the contact area of tire. It would lead to more fuel consumed for more power. And over inflation would cause much noise from the road surface, hard suspension. Proper tire inflation requires less power to drive vehicle moving.

Increase the drivers safety, protect companies assets
The TPMS function in gps tracking also protect the drivers, decreases the tires blown-up possibility. tire blown-up leads to severe accident. TPMS function would alerts driver or fleet management to take initiatives to handle the potential tires issues.
